Astec Tubes is a well established and leading manufacturers and suppliers of SS 316TI Flanges. We take pride to have served a large base of clients with our wide range of products. We have been a part of this industry for years.
Astec Tubes is a well established and leading manufacturers and suppliers of SS 316TI Flanges. We take pride to have served a large base of clients with our wide range of products. We have been a part of this industry for years.
Table Of Content
What is Stainless Steel 316Ti Flanges
Specification of ASTM A182 316Ti SS Pipe Flanges
Available Types of Stainless Steel 316Ti Flanges
Stainless Steel 316Ti Flanges Equivalent Grades
ASTM A182 SS 316Ti Pipe Flanges Chemical Composition
ANSI B16.5 SS 316Ti Flanges Mechanical Properties
Types of Stainless Steel 316Ti Flanges
These flanges are an austenitic alloy comprise of nickel, chromium, and iron. These are highly resistant to the effect of acid, particularly sulfur acid which is most lethal. It portrays excellent resistance to corrosion both pitting and crevice even in the presence of chemicals containing chlorides. It gives you similar resistance in the presence of sulfuric, phosphoric and nitric acids. SS 316 TI Flanges contain niobium. The presence of niobium gives stabilization to the product against sensitization.
These flanges are a terrific combination of corrosion resistance with enhanced mechanical properties and ease of fabrication. The crack corrosion resistance and pitting properties are one of the features due to which many industries use these flanges. One of the prime reasons for its popularity is its ability to withstand sulfuric and chloric acid attacks. The chemical composition of these fittings includes both nickel and molybdenum. Apart from that these show great flexibility to hot working practices if applied correctly.
It offers excellent resistance to most of the chemicals that is why it is apt for usage in paper and textile industries. In addition to that, it is known for having tremendous pitting resistance. These exhibit better corrosion resistance than most of its counterparts. With that, these flanges offer a high level of oxidation resistance. Its tensile strength makes it strong enough that it does not get damage if someone exposes it to temperatures well over 800 degrees F and that too for long periods. These flanges come as a value proposition for its end users.
These flanges are used in a wide variety of applications across many industries. Some of the prime examples of its usage are manufacturing parts of the furnace, in a pressure vessel and in tanks, in manufacturing industrial boiler and heat exchangers, etc. These flanges are not prone to leakage that is why it is used in processing industries. These flanges are cost effective as well.
Stainless Steel 316Ti Slip on Flanges
Stainless Steel 316Ti Weld Neck Flanges
Stainless Steel 316Ti Blind Flanges
Stainless Steel 316Ti Threaded Flanges
SS 316Ti Socket weld Flanges
Stainless Steel 316Ti Lap Joint Flanges
Stainless Steel 316Ti RTJ Flanges
Stainless Steel 316Ti Long Weld Neck Flanges
Stainless Steel 316Ti Spectacle Blind Flange
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
SS 316Ti | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17‐123 | X6CrNiMoTi17-12-2 |
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
SS 316Ti | 0.08 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 10.00 - 14.00 | 68.395 min |
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
UNS S31635 Flanges
Stainless Steel 316Ti Slip on Flanges
Stainless Steel 316Ti SORF Flanges
UNS S31635 Threaded Flanges
Stainless Steel 1.4571 Flanges
SUS 316Ti Pipe Flange Exporter
ANSI B16.5 SS 316Ti Orifice Flanges
Stainless Steel 316Ti Weld Neck Flanges
SS 316Ti WNRF Flanges
UNS S31635 SWRF Flange Supplier
SS 1.4571 Forged Flange
SUS 316Ti Long Weld Neck Flanges
ANSI B16.5 SS 316Ti Plate Flange
SS 316Ti Lap Joint Flanges
Stainless Steel 316Ti Blind Flanges
SS 316Ti RTJ Flanges Manufacturer
Stainless Steel 316Ti BLRF Flanges
UNS S31635 Plate Flanges Stockist
SS 1.4571 Reducing Flanges Stockholder
SUS 316Ti Ring Type Joint Flanges
ANSI B16.5 SS 316Ti Square Flange
ASME/ANSI B 16.5 | 316Ti Welding Neck Flange, 316Ti SS Slip on Flange, Stainless 316Ti Blind Flange, High Hub Blind Flange, 1.4571 Socket Weld Flange, S31635 Lap Joint Flange, SS 316Ti Threaded Flange, Ring Type Joint Flange |
ASME/ANSI B 16.47 | Welding Neck Flange, Blind Flange [Series A & B] |
ASME/ANSI B 16.36 | SUS 316Ti Welding Neck Flange, Slip on Flange, Threaded Flange |
BS 4504 SEC 3.1 | SS 316Ti Welding Neck Flange, Hubbed Slip on Flange, Hubbed Threaded Flange, Stainless 316Ti Lapped Pipe End Flange, Plate Flange, Loose Plate Flange, Steel 316Ti Loose Plate With Weld Neck Flange, Blank Flange |
BS 4504[PART 1] | Welding Neck Flange, Hubbed Slip-On Hubbed Threaded, Plate Flange, Loose Plate With Weld On Plate Collar, Blank Flange |
BS 1560 BOSS | Welding Neck Flange, Socket Welding Flange, Slip-On Flange, Blind Flange, Screwed Boss Flange, SS 316Ti Lapped Flange |
BS10 | Welding Neck Flange, Plate Slip-On Flange, 316Ti SS Screwed Boss Flange, Slip-On Boss Flange, Blind Flange |
TABLE | D, E, F, H |
DIN FLANGES | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673 |
ASTM A182 F316Ti SS Flanges
Specification : ASTM A182 / ASME SA182
Dimensions : ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Standard : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Size : 1/2" (15 NB) to 48" (1200NB)
Class / Pressure : 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
DIN Flanges : DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673
JIS Flanges : JIS B2220 5K, JIS B2220 10K, JIS B2220 16K, JIS B2220 20K
BS Flanges : BS4504 PN 6, BS 4504 PN 10, BS4504 PN 16, BS4504 PN 25, BS4504 PN 40, BS 4504 PN 64, BS 4504 PN 100, BS 4504 PN 160, BS 4504 PN 250, BS 10, BS Table D, BS Table E, BS Table F, BS Table H.
