• IS 3074 CEW 1 Annealed & CDW Tubes & Pipes

    IS 3074 CEW 1 Annealed and CDW Tubes & Pipes are high-quality carbon steel tubes designed for applications requiring superior mechanical strength, durability and precision. The CEW pipe full form is Cold Drawn Electric Welded, ensuring dimensional accuracy and smooth internal and external finishes. Astech Tube is a leading CEW Tubes Manufacturer, committed to deliver premium-quality IS 3074 CDW Tubes that meet industry standards. The cew pipe offers a minimum tensile strength of 687MPa and a minimum yield strength of 589MPa ensuring durability and capability to withstand harsh conditions.

    CEW 1 Is 3074 Round Tube, Size: 4 Od To 100 Od, HFIW Steel Tubes manufacturer India, is 3074 erw 1, is 3074 material, erw 1 is 3074 chemical composition, cew pipe full form, cdw tubes, cdw pipes, is 3074 equivalent material.

    The IS 3074 CEW 1 Annealed Tubes and IS 3074 CDW Pipes are used in automotive components, engineering applications, furniture manufacturing, and in general mechanical industries. Their high-quality finish and corrosion resistance make them ideal for shock absorbers, hydraulic systems, precision machinery and boiler tubing. These IS 3074 CEW Tubes adhere to IS: The 3074 or DIN standards to maintain the quality and reliability. The size range now includes an outer diameter (OD) from 6mm to 50.8mm and wall thickness from 1mm to 5mm which fits many applications. The IS 3074 2013 chemical composition guarantees uniformity and performance.

    Annealed Carbon Steel Pipes and CDW tubes have excellent dimensional accuracy, surface finish, and improved mechanical properties due to the cold drawing process. The annealing treatment improves ductility and reduces stress. We implement various quality checks, including chemical composition analysis, mechanical testing and non-destructive evaluations, to ensure each product meets the highest standards.

    Our IS 3074 Tubes Price is relatively affordable to ensure that our products can be used in various industries. These tubes are well packed to ensure they do not get damaged during transportation. We also assure the delivery of our products on time and safely. Whether you need IS 3074 CEW 1 Annealed Tubes or CDW Pipes, we give importance to quality, price and timely delivery. Choose us for the best quality IS 3074 CEW 1 Annealed Tubes and IS 3074 CDW Pipes as per your project needs.

    Size:

    • 19.05 to 114.3 mm OD

    Unit pipe length

    • 6 meters, customizable

    Material:

    MS / CS

    Outer diameter:

    • 5 mm to 1219.2 m

    Wall thickness:

    • 0.5 mm to 20 mm

    Pressure capacities:

    Sch5 through XXS and heavier

    Carbon content:

    Cew2 has 0.16%, cew 3 has 0.2, cew 4 has 0.25 and the cew 5 has 0.23%

    Coating:

    Galvanized, PTFE, 3LPE or any other relevant coating
    is-3074-cdw-tubes-steel-coating

    IS 3074 Cdw Tubes Steel Coating

    is-3074-steel-tube

    IS 3074 Steel Tube

    is-3074-erw-tube

    IS 3074 Erw Tube

    IS 3074 CEW 1 Annealed & CDW Tubes & Pipes Dimension Chart

    O.D. 1/2″-24″
    Size IS 3074 CEW 1 Annealed & CDW Tubes & Pipes Weight
    Schedule SCH 5S-SCH XXS
    Wall thickness 0.020″-0.220″
    Swg & Bwgs 12 Swg., 10 Swg., 18 Swg., 14 Swg., 16 Swg., 20 Swg.
    Carbon Steel Cold Drawn ERW Tube End Treaded Pipe, Plain End, Beveled End, Screwed ends
    Alloy Steel CEW Pipe Finish 2B, 8K, NO.1, MF, NO.4, BA, Mirror finish, BA, Polished, AP, HL
    CEW Steel Tubes Length 6mtr-18mtr, Single Random, Double Random & Required Length, Custom Size
    Steel Cew-1 Tubes Marking Thickness, Heat, Manufacturers logo, Standard, Length, Weight, End finish, Treatment, Impact, Grade and type, OD, Test temperature
    Cew Tube Material Inspection Checklist Approved lab test, Mechanical test, Destructive test, Flaring Test, Third party inspection, Chemical test, PMI test, Visual inspection
    Have you any question or query
    General Queries While Buying IS 3074 CEW 1 Annealed & CDW Tubes & Pipes

    Chemical Equation of IS 3074 CEW 1 Annealed & CDW Tubes & Pipes

    Grade Phosphorus & Sulfur Carbon Manganese Silicon
    CEW 2 .05 .16 .7
    CEW 3 .2 .9 .35
    CEW 4 .25 1.2
    CEW 5 .23 1.5 .5

    Mechanical Behaviour of IS 3074 CEW 1 Annealed & CDW Tubes & Pipes

    Condition Yield (N/mm2) Elongation (%) Tensile (N/mm2)
    NBK normalised 155 25 280
    GBK annealed 150 27 270
    BK as drawn 320 6 400

    IS 3074 CEW 1 Annealed & CDW Tubes & Pipes Weight

    The weight of CEW, CDW pipes and tubes depends on the size and other specifications:

    • TATA Cew Is 3074 Cdw Pipes Tubes: A 0.5 inch diameter TATA Cew Is 3074 Cdw Pipes Tubes weighs 1000 kg.
    • IS 3074 CEW 1 Annealed & CDW Tubes & Pipes: These tubes have a size range of 6 mm to 50.8 mm OD and a wall thickness of 1 mm to 5 mm.


    Types of IS 3074 CEW 1 Annealed & CDW Tubes & Pipes

    IS 3074 CEW 1 Annealed & CDW Tubes & Pipes Applications

    • Construction
    • Automotive
    • Heat exchangers
    • Petroleum industry
    • Bottom Chassis
    • Swing Arm
    • Two Wheeler Main Frame
    • Fuel Tank Spacer
