Stainless Steel 316/316L Flanges Manufacturer

ASTM A182 F316L SS Weld Neck Flanges, Stainless Steel 316 Flanges, SS 1.4401 / 1.4404 Socket weld Flanges, 316 SS Slip on Flanges, ANSI B16.5 Stainless Steel 316L Flanges, SS S31603 Flanges, SS 316L Flanges Suppliers in Mumbai, India.

Astec Tubes is a leading name in the industry for serving out the wide variety of SS 316 / 316L Flanges. Flanges are very important components of any piping industry for making a connection. Therefore, we produce all the common and special flanges for completing your need for flanges. In short, clients can get a wide range of flanges that differ in specifications and dimensions for their requirements.

Flanges are commonly a known product for providing a connection to the pipes. They are a very popular way of making a connection after the method of welding. On contrary to welding, flange connection allows easy dismantling of pipes hence they are popularly preferred. As a result, you get maintenance flexibility. The flanges can connect a pipe with various other components like valves and more. However, the connection is made using gaskets and bolts.

SS 316 Blind Flanges, Stainless Steel 316L Spectacle Blind Flanges, ASME SA 182 SS 316 Plate Flanges, 316L SS RTJ Flanges, SUS 316L Flanges, SS 1.4404 / 1.4435 Flange, Stainless Steel 316L Lap Joint Flanges, Stainless Steel 316 Pipe Flanges, 316L SS Industrial Flanges, SS 316 Flanges Manufacturer in India.

The SS 316 / 316L Flanges are classified based on connection to be made, flange facing types, material types, and pressure-temperature ratings. As per flanges types, there are threaded flanges, socket weld flanges, slip-on flanges, lap joint flanges, weld neck flanges, and blind flanges. And based on flange facing types, we produce tongue and groove type, male and female type; ring joint, raised face, and flat face. And when we talk about the pressure-temperature rating, the flanges are classified based on the alloy used to make it.

Our SS 316 / 316L Flanges have high-pressure temperature ratings that make them perfect product for withstanding high pressure and temperature. This is because the SS 316 and 316 L is most sought material for manufacturing these flanges. There better corrosion-resistant property is making them a widely used material. In addition to this, pitting resistant and crevice corrosion are few of the properties that make our flanges a highly demanded product.

Henceforth, many industries demand our flanges where they provide secure connections. Industries like rubber industry, chemical processing equipment, pollution control, paper and pulp industry, pharmaceutical industries, and more are demanding for these flanges. The low carbon variant of the stainless steel is also used for making these flanges of the highest quality.

Specification : ASTM A182 / ASME SA182

Dimensions : ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.

Standard : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.

Size : 1/2" (15 NB) to 48" (1200NB)

Class / Pressure : 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.

Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

DIN Flanges : DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673

JIS Flanges : JIS B2220 5K, JIS B2220 10K, JIS B2220 16K, JIS B2220 20K

BS Flanges : BS4504 PN 6, BS 4504 PN 10, BS4504 PN 16, BS4504 PN 25, BS4504 PN 40, BS 4504 PN 64, BS 4504 PN 100, BS 4504 PN 160, BS 4504 PN 250, BS 10, BS Table D, BS Table E, BS Table F, BS Table H.

Stainless Steel 316, 316L Slip on Flanges

Stainless Steel 316, 316L Slip on Flanges

Stainless Steel 316, 316L Weld Neck Flanges

SS 316, 316L Weld Neck Flanges

Stainless Steel 316, 316L Blind Flanges

Stainless Steel 316, 316L Blind Flanges

Stainless Steel 316, 316L Threaded Flanges

Stainless Steel 316, 316L Threaded Flanges

Stainless Steel 316, 316L Socket weld Flanges

Stainless Steel 316, 316L Socket weld Flanges

Stainless Steel 316, 316L Lap Joint Flanges

Stainless Steel 316, 316L Lap Joint Flanges

Stainless Steel 316 RTJ Flanges

SS 316, 316L RTJ Flanges

Stainless Steel 316, 316L Long Weld Neck Flanges

SS 316, 316L Long Weld Neck Flanges

Stainless Steel 316, 316L Spectacle Blind Flange

SS 316, 316L Spectacle Blind Flange

Stainless Steel 316/316L Flanges Equivalent Grades

STANDARD UNS WNR. AFNOR EN JIS BS GOST
SS 316 S31600 1.4401 / 1.4436 Z7CND17‐11‐02 X5CrNiMo17-12-2 / X3CrNiMo17-13-3 SUS 316 316S31 / 316S33 -
SS 316L S31603 1.4404 / 1.4435 Z3CND17‐11‐02 / Z3CND18‐14‐03 X2CrNiMo17-12-2 / X2CrNiMo18-14-3 SUS 316L 316S11 / 316S13 03Ch17N14M3 / 03Ch17N14M2
Have you any question or query
General Queries While Buying 316/316L SS Flanges

ASTM A182 316/316L Flanges Chemical Composition

Grade C Mn Si P S Cr Mo Ni Fe
316 0.08 max 2.0 max 1.0 max 0.045 max 0.030 max 16.00 - 18.00 2.00 - 3.00 11.00 - 14.00 67.845 min
316L 0.035 max 2.0 max 1.0 max 0.045 max 0.030 max 16.00 - 18.00 2.00 - 3.00 10.00 - 14.00 68.89 min

ANSI B16.5 SS 316/316L Flanges Mechanical Properties

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.0 g/cm3 1400 °C (2550 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %

Types of Stainless Steel 316/316L Flanges

Manufacturing Standards of Stainless Steel 316/316L Flanges Manufacturers in India & Globally

ASME/ANSI B 16.5 316 Welding Neck Flange, 316L SS Slip on Flange, Stainless 316L Blind Flange, High Hub Blind Flange, 1.4435 Socket Weld Flange, S31600 Lap Joint Flange, SS 316 Threaded Flange, Ring Type Joint Flange
ASME/ANSI B 16.47 Welding Neck Flange, Blind Flange [Series A & B]
ASME/ANSI B 16.36 SUS 316 Welding Neck Flange, Slip on Flange, Threaded Flange
BS 4504 SEC 3.1 SS 316L Welding Neck Flange, Hubbed Slip on Flange, Hubbed Threaded Flange, Stainless 316L Lapped Pipe End Flange, Plate Flange, Loose Plate Flange, Steel 316 Loose Plate With Weld Neck Flange, Blank Flange
BS 4504[PART 1] Welding Neck Flange, Hubbed Slip-On Hubbed Threaded, Plate Flange, Loose Plate With Weld On Plate Collar, Blank Flange
BS 1560 BOSS Welding Neck Flange, Socket Welding Flange, Slip-On Flange, Blind Flange, Screwed Boss Flange, SS 316L Lapped Flange
BS10 Welding Neck Flange, Plate Slip-On Flange, 316L SS Screwed Boss Flange, Slip-On Boss Flange, Blind Flange
TABLE D, E, F, H
DIN FLANGES DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673


Stainless Steel 316/316L Flanges Applications

  • Petrochemicals
  • Gas Processing
  • Chemical Equipment
  • Off-Shore Oil Drilling Companies
  • Pharmaceutical Equipment
  • Pulp & Paper Industry
  • Sea Water Equipment
  • Power Generation
